Railway Bridges
Railway bridge girder fabrication in Kolkata.
Steel girders for Indian Railways and for road bridges: open web, composite and plate girders, fabricated in the Kolkata yard under RDSO Part A approval and ISO 9001, held by Unit 1, Domjur.
RDSO Part A approved girder fabrication.
The factory unit at Domjur (Unit 1) is approved under ISO 9001 and holds RDSO approval under Part A for the fabrication of open web, composite and other steel plate girders. RDSO is the Research Designs and Standards Organisation of Indian Railways.
- Railway girders made to the railway’s drawings and specification
- An inspection schedule and records with every span
- Road bridges, road overbridges and foot overbridges built in the same yard to the same discipline
- RDSO
- Approved under Part A: open web, composite and other steel plate girders
- Quality system
- ISO 9001
- Girder types
- Open web (through-truss) girders, composite girders, plate girders
- Bridge types
- Railway bridges, road bridges, road overbridges (ROB), foot overbridges (FOB)
- Bridges
- Railway bridge girders for Eastern Railway, and the Government of Sikkim’s 50 m road bridge.
- Clients
- Nine zonal railways of Indian Railways and IRCON, with the Government of Sikkim, Sikkim PWD, Sikkim Tourism and KMDA
- Yard
- Unit 1, Domjur, Howrah, the unit named in the RDSO letter: 150,000 sq ft
Open web, composite and plate girders.
Open web girders
Through-truss and other open web spans, built up from top and bottom chords, verticals and diagonals. Members are cut from plate on the CNC plasma cutting machine and assembled in the yard to the customer’s drawings. The photographs on this page show them in bare steel in the yard, and in service on piers.
Composite girders
A concrete deck that acts together with the steel section beneath it. The steel part is fabricated here to the drawing and the railway’s inspection schedule, then sent to site, where the deck is cast on top.
Plate girders
Welded up from flange and web plates, for railway spans, road overbridges and foot overbridges. Every girder is checked at each stage against the quality assurance plan written for its order, then blast cleaned and painted.
Projects
Bridge girders, in the yard and on site.
Bridge clients.
Railway bridge girders for Eastern Railway and a 50 m road bridge for the Government of Sikkim; both scopes are on the clients page. The list also names IRCON, South Eastern Railway, Northeast Frontier Railway, South Coast Railway, East Coast Railway, North Central Railway, South Western Railway, East Central Railway, South East Central Railway, Sikkim PWD, KMDA and Sikkim Tourism.
Also: IRCON, South Eastern Railway, Northeast Frontier Railway, South Coast Railway, East Coast Railway, North Central Railway, South Western Railway, East Central Railway, South East Central Railway, Sikkim PWD, KMDA (Kolkata Metropolitan Development Authority), Sikkim Tourism and Government of Sikkim.
Bridge girder FAQs.
Do you fabricate bridge girders?
Yes. Metal Craft Engineering has fabricated rail bridge girders for Eastern Railway and a 50 m public road bridge for the Government of Sikkim. The About page has photographs of a through-truss girder assembled in the fabrication yard.
Are your works RDSO approved?
Yes, at Unit 1, Domjur. The factory unit there is approved under ISO 9001 and holds RDSO approval under Part A for the fabrication of open web, composite and other steel plate girders. Girders for railway bridges are fabricated to the railway’s drawings and inspection schedule; the RDSO-approved girder fabrication is at Unit 1, Domjur, the unit named on the RDSO letter. The details of RDSO’s Final Decision Letter No. RDSO/108/1901/00024414 of 1 September 2022 are on the Vendor Approval RDSO page.
